ELECTRICAL SYSTEM 16-5

Exploded View

Torque

No. Fastener

N·m kgf·m ft·lb

Remarks

1 Alternator Rotor Bolt 69 7.0 51 Lh

2 Alternator Stator Allen Bolts 12 1.2 104 in·lb

3 Crankshaft Sensor Mounting Screws 8.3 0.85 74 in·lb L

4 Spark Plugs 14 1.4 10

5 Starter Clutch Allen Bolts 34 3.5 25 L

6 Starter Chain Guide Bolts 4.9 0.5 43 in·lb L

Starter M otor Terminal Nut

4.9 0.5 43 in·lb

8 Starter Motor Mounting Bolts 11 1.1 95 in·lb

9 Starter Motor Lead Clamp Nut 4.9 0.5 43 in·lb

10 Starter Motor Through Bolts 6.9 0.7 65 in·lb

11 Water Temperature Switch 7.8 0.8 69 in·lb SS

12 Radiator Fan Switch 18 1.8 13

Oil Pressure Switch

15 1.5 11

14 Oil Pressure Switch Terminal Bolt 1.5 0.15 13 in·lb

15 Neutral Switch 15 1.5 11

16 Alternator Cover Bolts 11 1.1 95 in·lb

17 Timing Inspection Plug 2.5 0.25 22 in·lb

18 Alternator Rotor Bolt Plug 1.5 0.15 13 in·lb

19. Regulator/Rectifier

20. Ignition Coils

21. IC Igniter

22. Starter Relay

23. Main Fuse 30 A

EO: Apply engine oil.

L: Apply a non-permanent locking agent.

Lh: Left-hand Thread

SS: Apply Silicone Sealant.
