1-4 GENERAL INFORMATION

Before Servicing

Tightening Sequence

Generally, when installing a part with s everal bolts, nuts,

or screws, start them all in their holes and tighten them to

a snug fit. Then tighten them according to the specified se-

quence to prevent case warpage or deformation which can

lead to malfunction. Conversely when loosening the bolts,

nuts, or screws, first loosen all of them by about a quar-

ter turn and them remove them. If the specified tightening

sequence is not indicated, tighten the fasteners alternating

diagonally.

Tightening Torque

Incorrect torque applied to a bolt, nut, or screw may

lead to serious damage. Tighten fasteners to the specified

torque using a good quality torque wrench.

Force

Use common sense during disassembly and assembly,

excessive force can cause expensive or hard to repair dam-

age. When necessary, remove screws that have a non

-permanent locking agent applied using an impact driver.

Use a plastic-faced mallet whenever tapping is necessary.

Gasket, O-ring

Hardening, shrinkage, or damage of both gaskets

and O-rings after disassembly can reduce sealing per-

formance. Remove old gaskets and clean the sealing

surfaces thoroughly so that no gasket material or other

material remains. Install new gaskets and replace used

O-rings when re-assembling.

Liquid Gasket, Locking Ag ent

For applications that require Liquid Gasket or a Locking

agent, clean the surfaces so that no oil residue remains be-

fore applying liquid gasket or locking agent. Do not apply

them excessively. Excessive application can clog oil pas-

sages and cause serious damage.
