Konica Minolta CF5001 [118/432] Output mode for machine with finisher continued
![Konica Minolta CF5001 [118/432] Output mode for machine with finisher continued](/views2/1122213/page118/bg76.png)
Output Mode for Machine with Finisher (continued)
3-50
See p. 3-10 for details on setting print quantity.
8. Position original(s).
See p. 3-4 to p. 3-9 for details on positioning originals.
9. Press [START].
Press [STOP] to suspend the scanning or printing job. See p. 3-13 for details.
Finisher primary (main) tray of Finisher FN-120/FN-9 gradually goes down
while printed materials output. DO NOT allow any object to interfere with the
operation of the tray on the left side of the finisher, as any interference may
cause damage to the finisher.
When the finisher exit tray capacity is exceeded due to the print
quantity selected, remove the copied sets as they exit; otherwise,
mishandled paper will occur.
Output Icons on the Basic Screen
Non-sort Sort (offset) Group (offset)
Non-sort Sort (offset) Group (offset)
Primary (Main) tray: Face up
Primary (Main) tray: Face down
