Turning On the Power Switch (continued)
2-18
To Turn Off the Power
1. Turn OFF the power switch.
The power switch is located on the left side of the control panel.
The touch screen and all the LEDs on the control panel will go out.
Be sure not to use the main power switch in usual operation.
When the machine is under control of the Weekly Timer function, turning off
the power switch will deactivate the function.
