Making a Multiple Page Signature Booklet (Booklet)
(continued)
10-15
See p. 3-10 for details on setting print quantity.
10. Position originals FACE UP in the document feeder.
• For details on positioning originals, see p. 3-4 to p. 3-7.
• Use RADF store mode (p. 3-33 to p. 3-34) when the original count exceeds
100.
Original pages should be a multiple of 4 in 1-2 mode or a multiple of 2 in 2-2
mode; otherwise blank pages are automatically inserted to the last.
When loading originals, heed the following limits on capacity:
Fold mode 12 pages or less for simplex copying
6 pages or less for duplex copying
Stitch & Fold mode80 pages or less for simplex copying
40 pages or less for duplex copying
Exceeding the above limits on capacity may cause misfeeds in the finisher.
11. Press [START].
When the finisher / paper exit tray capacity is exceeded due to the
print quantity selected, remove the copied sets as they exit;
otherwise, mishandled paper will occur.
When the Booklet / Trimmer unit tray capacity is exceeded, the
finisher / trimmer unit will cease operating. To avoid such trouble,
select an appropriate print quantity from the specifications on p. 12-
4.
