Machine Configuration (continued)
2-10
FN-120/FN-9 Finisher (with PK-5 Punch Kit)
1 Finisher door opens to the internal Finisher to allow clearing mishandled paper,
replenishing staples, and emptying waste basket of Punch kit.
2Booklet tray (FN-9 Finisher only) holds sets output in Fold mode, Stapling &
Fold mode, or Three-fold mode.
3 Primary (Main) tray holds sets output in Non-sort mode, Sort mode (offset),
Staple-sort mode, or Group mode (offset).
4 Secondary (Sub) tray holds sets output in Sort mode or Group mode with face
down/up mode.
1 Finisher door1 Finisher door
2 Booklet tray
(FN-9 Finisher only)
3 Primary
(Main) tray
3 Primary
(Main) tray
4 Secondary
(Sub) tray
4 Secondary
(Sub) tray
FN-9 Finisher
FN-120 Finisher
