Paper Information (continued)
12-4
Tray/ Exit Tray Capacity
Paper Trays Capacity
Tray 1, 2, and 3
(Main body tray)
500 sheets (90 g/m
2
paper)
LCT (C-208) 2,500 sheets (90 g/m
2
paper)
Multi-sheet bypass tray
250 sheets (90 g/m
2
paper)
1 sheet each for offset master or Label.
OHP film or ink-jet paper is unavailable.
Equipments Capacity
ADU Unlimited
Finisher
(FN-120/
FN-9)
Secondary (sub)
tray
Approx. 100 sheets
(More than 100 sheets available dependent on paper
type or weight.)
Primary (main)
tray
Non-sort mode (80 g/m
2
paper)
500 sheets (A5R, B6R)
3,000 sheets (A4, A4R, B5, B5R) (FS-115)
2,500 sheets (A4, A4R, B5, B5R, 8.5”x11”, 8.5”x11”R) (FS-215)
1,500 sheets (A3, B4, 12”x18”, 11”x17”, 8.5”x14”)
Sort/Group mode (80 g/m
2
paper)
3,000 sheets (8.5”x11”, 8.5”x11”R, A4, A4R, B5, B5R) (FS-115)
2,500 sheets (8.5”x11”, 8.5”x11”R, A4, A4R, B5, B5R) (FS-215)
1,500 sheets (12”x18”, 11”x17”, 8.5”x14”, A3, B4)
Staple-sort mode (80 g/m
2
paper)
1,000 sheets
(Variable according to the number of pages to be
stapled. See p. 12-5 for details)
Finisher
(FN-9)
Booklet tray
100 sheets (A3, B4, 12”x18”, 11”x17”, 8.5”x14”) (80 g/m
2
paper)
Fold: 33 sets for 3-sheet-folded booklet
(33 x 3 = 99 sheets, 396 pages)
Stitch&Fold: 20 sets for 5-sheet-folded booklet
(20 x 5 = 100 sheets, 400 pages)
5 sets for 20-sheet-folded booklet
(5 x 20 = 100 sheets, 400 pages)
75 sheets (A4R, 8.5”x11”R) (80 g/m
2
paper)
Fold: 25 sets for 3-sheet-folded booklet
(25 x 3 = 75 sheets, 300 pages)
Stitch&Fold: 12 sets for 5-sheet-folded booklet
(15 x 5 = 75 sheets, 300 pages)
3 sets for 25-sheet-folded booklet
(3 x 25 = 75 sheets, 300 pages)
* Maximum number of folded sheet is 3 for Fold mode,
and 25 for Stitch & Fold mode.
Cover Inserter D
200 sheets (200 g/m
2
) or 30 mm thick for Upper/lower tray
Punch kit (PK-5) Unlimited
Trimming unit (TMG-3) 512 sheets (80 g/m
2
paper) (See p. 8-16 for details)
Exit tray 150 sheets (90 g/m
2
paper)
