Locating Title Pages on the Right Side (Chapter) (continued)
10-9
6. Enter the desired print quantity from the control panel keypad.
See p. 3-10 for details on setting print quantity.
7. Position originals FACE UP in the document feeder.
• For details on positioning originals, see p. 3-4 to p. 3-7.
• Use RADF store mode (p. 3-33 to p. 3-34) when the original count exceeds
100.
8. Press [START].
When the finisher / trimmer unit / paper exit tray capacity is
exceeded due to the print quantity selected, remove the copied sets
as they exit; otherwise, mishandled paper will occur.
