Making Trimmed Booklets (Trimming) (continued)
8-18
6. Enter the desired print quantity from the control panel keypad.
See p. 3-10 for details on setting print quantity.
7. Position originals.
See p. 3-4 to p. 3-9 for details on positioning originals.
When loading originals, heed the following limits on capacity:
Fold mode:
12 pages or less for simplex copying
6 pages or less for duplex copying
Stitch & Fold mode:
80 pages or less for simplex copying (80 g/m
2
paper only)
40 pages or less for duplex copying (80 g/m
2
paper only)
Exceeding the above capacity limits may cause trouble in the Finisher.
8. Press [START].
When the Trimmer unit tray capacity is exceeded, the Finisher and
Trimmer unit will cease operating. To avoid this, select the
appropriate print quantity from the specifications shown on p. 8-16.
