STANDARD ACCESSORIES
In addition to the main unit (1), the package contains
the accessories listed in the table below.
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (BCL1415)
(For DV14DCL2)
2. Battery (BCL1815)
(For DV18DCL2)
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Drilling of brick and concrete block, etc..
䡬 Driving and removing of machine screws, wood
screws, tapping screws, etc..
䡬 Drilling of various metals.
䡬 Drilling of various woods.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch
(2 pcs.) to remove the battery (see Figs. 1 and 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to the receptacle.
When the power cord is connected, the charger’s
pilot lamp will blink in red. (At 1-second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger till it
contacts the bottom of the charger and checking
the polarities as shown in Fig. 3.
CAUTION
䡬 If the battery is inserted in the reverse direction,
not only recharging will become impossible, but it
may also cause problems in the charger such as
deformed recharging terminal.
3. Charging
When inserting a battery in the charger, charging
will commence and the pilot lamp will light up
continuously in red.
When the battery becomes fully recharged, the pilot
lamp will blink in red (At 1-second intervals) (See
Table 1).
SPECIFICATIONS
POWER TOOL
Model DV14DCL2 DV18DCL2
No-load speed (Low/High) 0–400/0–1500 min
–1
0–400/0–1500 min
–1
No-load impact rate (Low/High) 0 – 5600 / 0 – 21000 min
–1
0–5600 / 0 – 21000 min
–1
Brick
(Depth 30 mm)
13 mm 13 mm
Wood
Drilling
(Thickness 18 mm)
32 mm 38 mm
Capacity Metal
(Thickness 1.6 mm)
13 mm 13 mm
Machine screw 6 mm 6 mm
Driving
Wood screw
8 mm (diameter) × 50 mm (length) 8 mm (diameter) × 75 mm (length)
(Requires a pilot hole) (Requires a pilot hole)
Rechargeable battery
BCL1415: Li-ion 14.4 V (1.5 Ah 4 cells) BCL1815: Li-ion 18 V (1.5 Ah 5 cells)
Weight 1.5 kg 1.6 kg
CHARGER
Model UC18YKL
Charging voltage 7.2 – 18V
Weight 0.4 kg
DV14DCL2
1 Plus driver bit (No. 2 × 65L) ................ 1
DV18DCL2
2 Charger ................................................. 1
3 Plastic case .......................................... 1
10. Do not use in a location where strong static
electricity generates.
11. If there is battery leakage, foul odor, heat
generated, discolored or deformed, or in any way
appears abnormal during use, recharging or
storage, immediately remove it from the equipment
or battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and
contact a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin
irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return
it to your supplier or vendor.
01Eng_DV14DCL2_EE 12/4/09, 4:239
