EDS-828 Series Getting Started

2-4

7. The EDS-828’s Main Menu will be displayed. (NOTE: To modify the appearance of the PComm Terminal

Emulator window, select Font… under the Edit menu, and then choose the desired formatting options.)

8. After entering the Main Menu, use the following keys to move the cursor, and to select options.

Key Function

Up/Down/Left/Right arrows, or Tab Move the onscreen cursor

Enter Display & select options

Space Toggle options

Esc Previous Menu

Configuration by Telnet Console

You may use Telnet to access the EDS-828’s console utility over a network. To be able to access the EDS’s

functions over the network (by Telnet or Web Browser) from a PC host that is connected to the same LAN as the

EDS-828, you need to make sure that the PC host and the EDS-828 are on the same logical subnetwork. To do

this, check your PC host’s IP address and subnet mask. By default, the EDS-828’s IP address is

192.168.127.253 and the EDS-828’s subnet mask is 255.255.255.0 (for a Class C network). If you do not

change these values, and your PC host’s subnet mask is 255.255.255.0, then its IP address must have the form

192.168.127.xxx. On the other hand, if your PC host’s subnet mask is 255.255.255.0, then its IP address must

have the form 192.168.127.xxx.

NOTE

To use the EDS

828’s management and monitoring functions from a PC host connected to the same LAN as

the EDS

-828, you must make sure that the PC host and the EDS-828 are on the same logical subnetwork.

NOTE

Before accessing the console utility via Telnet, first connect one of the EDS

828’s RJ45 Ethernet ports to your

Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a connecti

on with either a

straight

-through or cross-over Ethernet cable.

NOTE

The EDS

-828’s default IP is 192.168.127.253.
