Moxa EDS-82810G [72/113] Eds 828 series featured functions

EDS-828 Series Featured Functions

3-59

Email Alarm Events Settings

Event Types

Event Types can be divided into two basic groups: System Events and Port Events. System Events are

related to the overall function of the switch, whereas Port Events are related to the activity of a specific port.

System Event Warning e-mail is sent when…

Switch Cold Start Power is cut off and then reconnected.

Switch Warm Start The EDS-828 is rebooted, such as when network parameters are changed (IP

address, subnet mask, etc.).

Power Transition (OnOff) The EDS-828 is powered down.

Power Transition (OffOn) The EDS-828 is powered up.

DI1 (OnOff) Digital Input 1 is triggered by on to off transition

DI1 (OffOn) Digital Input 1 is triggered by off to on transition

DI2 (OnOff) Digital Input 2 is triggered by on to off transition

DI2 (OffOn) Digital Input 2 is triggered by off to on transition

Configuration Change

Activated

Any configuration item has been changed.

Comm. Redundancy Topology

Changed

If any Spanning Tree Protocol switches have changed their position (applies

only to the root of the tree).

If the Master of the Turbo Ring has changed or the backup path is activated.

Authentication Failure An incorrect password is entered.

Port Event Warning e-mail is sent when…

Link-on The port is connected to another device.

Link-off The port is disconnected (e.g., the cable is pulled out, or the opposing device

shuts down).

Traffic-Overload The port’s traffic surpasses the Traffic-

Threshold for that port (provided this

item is Enabled).

Traffic-Threshold (%) Enter a nonzero number if the port’s Traffic-Overload item is Enabled.

Traffic-Duration (sec.) A Traffic-Overload warning is sent every Traffic-Duration seconds if the

average Traffic-Threshold is surpassed during that time period.
