EDS-828 Series Featured Functions

3-73

The EDS-828 can efficiently update and maintain the routing table, and optimize the routing by identifying the

smallest metric and most matched mask prefix.

Interface Setting

The IP Interface Setting page is used to assign the interface.

Interface Name

Used to describe this interface (max. of 15 characters.)

IP Address

This option is used to specify the IP address of this interface.

Subnet Mask

This option is used to specify the subnet mask for this IP address.

VLAN ID

Setting Description Factory Default

ID numbers Display all available VLAN IDs that you have set in the Virtual

LAN. To establish an interface, you must first assign an

available ID to

this interface. If a VLAN ID is assigned twice, a

warning message will appear.

None (if no VLAN ID

is available)

Proxy ARP

Setting Description Factory Default

Enable/Disable This option is used to enable or disable the Proxy ARP. Disabled

There are three action buttons for setting up the IP Interface Table:

Add

To add a entry into the IP Interface Table

Delete

To remove the selected entries from the IP Interface Table

Modify

To modify the content of a selected entry in the IP Interface Table
