EDS-828 Series Featured Functions

3-67

Type

Setting Description Factory Default

IP Use switch IP address as the remote ID sub-option. IP

MAC Use switch MAC address as the remote ID sub-option. IP

Client-ID Use the

combination of switch MAC address and IP address as

the remote ID sub-option.

Other Use the user-defined value as the remote ID sub-option. IP

Value

Setting Description Factory Default

Displays the value which you’ve set.

Max. 12 characters If you set the DHCP Option 82 type as Other, you will need to

set it here.

switch IP address

Display

Setting Description Factory Default

The actual hexdecimal value set at the DHCP server for the

Remote-ID. This value is automatically generated according to

the Value field. Users can not modify it.

COA87FFD

DHCP Function Table

Enable

Setting Description Factory Default

Enable or Disable Enable or disable DHCP Option 82 function for this port. Disable

Using Diagnosis

The EDS-828 provides two important tools for administrators to diagnose network systems.

Mirror Port

The Mirror port function can be used to monitor data being transmitted through a specific port. This is done

by setting up another port (the mirror port) to receive the same data being transmitted from, or both to and

from, the port under observation. This allows the network administrator to “sniff” the observed port and thus

keep tabs on network activity.
