Moxa EDS-82810G [25/113] System file update by local import export

EDS-828 Series Featured Functions

3-12

Configuration file path and name

Setting Description Factory Default

Max. 40 Characters The path and file name of the EDS-828’s configuration file in

the TFTP server.

None

Firmware file path and name

Setting Description Factory Default

Max. 40 Characters The path and file name of the EDS-828’s firmware file. None

Log file path and name

Setting Description Factory Default

Max. 40 Characters The path and file name of the EDS-828’s log file None

After setting up the desired path and file name, click on Activate to save the setting, and then click on

Download to download the prepared file from the remote TFTP server, or click on Upload to upload the

desired file to the remote TFTP server.

System File Update—By Local Import/Export

Configuration File

To export the configuration file of this EDS-828, click on Export to save it to the local host.

Log File

To export the Log file of this EDS-828, click on Export and save it to the local host.

NOTE

Some operating systems will open the configuration file and log file directly in the web page. In such cases,

right click on the “Export” button to save a f

ile.

Upgrade Firmware

To import the firmware file of this EDS-828, click on Browse to select the firmware file already saved on your

computer. The upgrade procedure will proceed automatically after clicking on Import.

Upload Configure Data

To import the configuration file of this EDS-828, click on Browse to select the configuration file already saved

on your computer. The upgrade procedure will proceed automatically after clicking on Import.
