EDS-828 Series Getting Started

2-2

RS-232 Console Configuration (115200, None, 8,

1, VT100)

NOTE

Connection Caution!

1. You cannot connect to the EDS-828 simultaneously by serial console and Telnet.

2. You can connect to the EDS-

828 simultaneously by web browser and serial console, or by web browser

and Telnet.

However, we strongly suggest that you do NOT use more than one connection method at the same time.

Following this advice will allow you to maintain better control over the configuration of your EDS-828.

NOTE

We recommend using Moxa PComm Terminal Emulator, which can be downloaded free of charge from Moxa’s

website.

Before running PComm Terminal Emulator, use an RJ45 to DB9-F (or RJ45 to DB25-F) cable to connect the

EDS-828’s RS-232 Console port to your PC’s COM port (generally COM1 or COM2, depending on how your

system is set up).

After installing PComm Terminal Emulator, take the following steps to access the RS-232 Console utility.

1. From the Windows desktop, click on Start



Programs



PCommLite1.3



Terminal Emulator.

2. Select Open under Port Manager to open a new connection.
