EDS-828 Series Featured Functions

3-51

GMRP enable

Setting Description Factory Default

Enable/Disable Click the check box to enable the GMRP function for the port

listed in the Port column

Disable

GMRP Table

The EDS-828 displays the current active GMRP groups that were detected

GMRP Status

Setting Description

Fixed Ports This multicast address is defined by static multicast.

Learned Ports This multicast address is learned by GMRP.

Multicast Filtering Behavior

You can use the following table to configure the multicast filtering behavior for each port. GMRP is a MAC-based

multicast management protocol, whereas IGMP is IP-based. GMRP provides a mechanism that allows bridges

and end stations to register or un-register Group membership information dynamically.

Multicast Filtering Behavior

Setting Description Factory Default

Forward All Select to forward all multicast frames. Forward Unknown

Forward Unknown Select to forward unknown multicast frames.

*Note: When IGMP snooping / GMRP is enabled, or the

unknown multicast frame has been added into

Static Multicast

Address list, the unknown multicast frame will be discarded.

Filter Unknown Select to filter unknown multicast frames.
