EDS-828 Series Featured Functions
3-57
Local User Database Setup
Setting Description Factory Default
User Name
(Max. 30 characters)
User Name for Local User Database None
Password
(Max. 16 characters)
Password for Local User Database None
Description
(Max. 30 characters)
Description for Local User Database None
NOTE
The user name for the Local User Database is case
-insensitive.
Port Access control Table
The port status will show authorized or unauthorized.
Configuring Static Port Lock
The EDS-828 also supports adding multicast groups manually if required.
Add Static Unicast MAC Address
Setting Description Factory Default
MAC Address Add the static unicast MAC address into the address table. None
Port Fix the static address with a dedicated port. 1-1
