EDS-828 Series Featured Functions

3-62

Relay Alarm Event Settings

Event Types

Event Types can be divided into two basic groups: System Events and Port Events. System Events are

related to the overall function of the switch, whereas Port Events are related to the activity of a specific port.

The EDS-828 supports two relay outputs. You can configure which relay output is related to which events. This

helps administrators identify the importance of the different events.

System Event Warning Relay output is triggered when…

Power Transition (OnOff) The EDS-828 is powered on.

Power Transition (OffOn) The EDS-828 is powered down.

DI1 (OnOff) Digital Input 1 is triggered by on to off transition

DI1 (OffOn) Digital Input 1 is triggered by off to on transition

DI2 (OnOff) Digital Input 2 is triggered by on to off transition

DI2 (OffOn) Digital Input 2 is triggered by off to on transition

Turbo Ring Break Turbo Ring is broken

Port Event Warning e-mail is sent when…

Link-on The port is connected to another device.

Link-off The port is disconnected (e.g., the cable is pulled out, or the opposing device

shuts down).

Traffic-Overload The port’s traffic surpasses the Traffic-Threshold for that port (provided this

item is Enabled).

Traffic-Threshold (%) Enter a nonzero number if the port’s Traffic-Overload item is Enabled.

Traffic-Duration (sec.) A Traffic-Overload warning is sent every Traffic-Duration seconds if the

average Traffic-Threshold is surpassed during that time period.
