D-Link DWL-8200AP User Manual
Three Operational Modes
Operation Mode Function
Access Point (AP)
Create a wireless LAN (WLAN)
WDS with AP
Wirelessly connect multiple networks while still
functioning as an access point.
WDS
Wirelessly connect multiple networks.
