12
D-Link DWL-8200AP User Manual
Installation
1 You will need broadband Internet access.
2 Consult with your Cable or DSL provider for proper installation of the modem.
3 Connect the Cable or DSL modem to a Router.
(See the printed Quick Installation Guide included with your router.)
4 Connect the Ethernet Broadband Router to the PoE base unit.
(See the printed Quick Installation Guide included with the DWL-8200AP.)
5 Connect the DWL-8200AP to the PoE base unit.
(See the printed Quick Installation Guide included with the DWL-8200AP.)
6 If you are connecting a desktop computer to your network, install the D-Link
DWL-AG530 wireless PCI adapter into an available PCI slot on your desktop
computer.
(See the printed Quick Installation Guide included with the DWL-AG530.)
7 Install the drivers for the D-Link DWL-AG660 wireless Cardbus adapter into a
laptop computer.
(See the printed Quick Installation Guide included with the DWL-AG660.)
