36
D-Link DWL-8200AP User Manual
Home > Advanced Settings > Multi-SSID
When Multi-SSID is enabled, you can configure your SSIDs for either
both, 11a only, or 11g only networks.
Check to use a VLAN.
Select the wireless band (IEEE802.11a or IEEE802.11g).
You can select up to 7 multi-SSIDs per band, the default multi-SSIDs
is the primary, which puts the total to 8 multi-SSIDs per band.
Service Set Identifier (SSID) is the name designated for a specific
wireless local area network (WLAN). The SSID’s factory default
setting is dlink. The SSID can be easily changed to connect to an
existing wireless network or to establish a new wireless network.
Select Disable to prevent the SSID name to be broadcast.
Enable Multi-SSID:
Enable VLAN Status:
Band:
Index:
SSID:
SSID Broadcast:
