34
D-Link DWL-8200AP User Manual
Super Mode
without Turbo:
Super Mode
with Static
Turbo:
Super Mode
with Dynamic
Turbo:
WMM:
Capable of Packet Bursting, FastFrames, Compression,
and no Turbo mode.
Capable of Packet Bursting, FastFrames, Compression,
and Static Turbo. This setting is not backwards
compatible with non-Turbo (legacy) devices. Static
turbo mode is always on and is only enabled when
all the devices on the wireless network are configured
with Super Mode with Static Turbo enabled.
Note: Super Mode with Static Turbo is only available
for 802.11a.
Capable of Packet Bursting, FastFrames, Compression,
and Dynamic Turbo.
This setting is backwards
compatible with non-Turbo (legacy) devices.
Dynamic
Turbo Mode is only enabled when all
devices on the wireless network are configured with
Super Mode with Dynamic Turbo enabled.
(Wi-Fi Multimedia) Improves the user experience for audio, video,
and voice applications over a Wi-Fi network. WMM is based on a
subset of the IEEE 802.11e WLAN QoS standard.
Antenna Diversity:
The Preamble Type defines the length of the CRC (Cyclic
Redundancy Check) block for communication between the Access
Point and roaming wireless adapters. The default setting is set to
“Short and long” Preamble.
Note: High network traffic areas should use the shorter preamble
type. CRC is a common technique for detecting data transmission
errors.
Preamble
(802.11g only):
This function allows you to configure the wireless network with IEEE
802.11g only, IEEE 802.11b only, or IEEE 802.11g with backward
interoperability with IEEE 802.11.
Wireless B/G Mode
(802.11g only):
This option is enabled by default. When enabled, each radio (5GHz/
2.4GHz) will automatically switch to the antenna with the greatest
RSSI value. When disabled, each radio will use its main antenna -
when facing the AP, 5GHz will use the right antenna to transmit and
receive packets while the 2.4GHz radio will use the left.
