33
D-Link DWL-8200AP User Manual
*Maximum wireless signal rate derived from IEEE Standard 802.11a and 802.11g specifications. Actual data throughput will vary.
Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network
overhead lower actual data throughput rate.
Data Rate*:
Beacon Interval
(20-1000):
DTIM (1-255):
Fragmentation
Length (256-2346):
RTS Length
(256-2346):
Transmit Power:
Super Mode:
The default value is set to “Auto”, which adjusts the base transfer
rate depending on the base rate of the connecting device. The Data
Rates are Auto, 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps,
36Mbps, 48Mbps, 54Mbps.
Beacons are packets sent by an Access Point to synchronize a
wireless network. Specify a Beacon interval value between 20 and
1000. The default value is set to 100 milliseconds.
(Delivery Traffic Indication Message) - Select a setting between 1
and 255. 1 is the default setting. DTIM is a countdown informing
clients of the next window for listening to broadcast and multicast
messages.
The fragmentation threshold, which is specified in bytes, determines
whether packets will be fragmented. Packets exceeding the 2346
byte setting will be fragmented before transmission. 2346 is the
default setting.
This value should remain at its default setting of 2346. If you
encounter inconsistent data flow, only minor modifications to the
value range between 256 and 2346 are recommended.
Choose full, half (-3dB), quarter (-6dB), eighth (-9dB), minimum
power.
Super Mode is a group of performance enhancement features that
increase end user application throughput in an 802.11a and 802.11g
network. Super Mode is backwards compatible to standard 802.11g
devices. For top performance, all wireless devices on the network
should be Super Mode capable. Select either Disabled, Super Mode
without Turbo, Super Mode with Static Turbo, or Super Mode with
Dynamic Turbo.
Disabled:
Standard 802.11a and 802.11g support, no enhanced
capabilities.
