50
D-Link DWL-8200AP User Manual
Home > Status > WDS Information
Displays the MAC address of the client.
MAC:
Displays the wireless band the client is connected on.
Band:
Displays the type of authentication being used.
Authentication:
Displays the strength of the clients signal.
Signal:
Displays the wireless channel being used.
Channel:
Displays the SSID the client is connected to.
SSID:
