56
D-Link DWL-8200AP User Manual
Tool > Administrator Settings
Login Settings
Old Password:
When changing your password, enter the old password here.
User Name:
Enter a user name. The default is admin.
When changing your password, enter the new password here.
Confirm New
Password:
Confirm your new password here.
New Password:
