57
D-Link DWL-8200AP User Manual
Status:
Status is Enabled by default. Un-check the box to disable the
console.
Console Settings
Console Protocol:
Select the type of protocol you would like to use, Telnet or SSH.
SNMP Settings
Public Community
String:
Enter the public SNMP community string.
Status:
Status is Enabled by default. Un-check the box to disable the
SNMP functions.
Private Community
String:
Enter the private SNMP community string.
