46
D-Link DWL-8200AP User Manual
Wireless Band:
Access Control:
MAC Address:
MAC Address List:
Select IEEE 802.11a or IEEE 802.11g.
Enter the MAC addresses that you wish to include in your filters
list, and click Save.
When you enter a MAC address, it appears in this list. Highlight a
MAC address and click Delete to remove it from the list.
Select Disabled to disable the filters function.
Select Accept to accept only those devices with MAC addresses
in the Access Control List.
Select Reject to reject the devices with MAC addresses in the
Access Control List.
> Wireless MAC ACL
Home > Advanced Settings >Filters
