D-Link DWL-8200AP User Manual
The Multi-SSIDs security can be WPA/WPA2-Enterprise or
WPA-Auto-Enterprise only when the Primary SSID’s security is at the
same security level. Also, they must connect to the same RADIUS
server.
Select “LAN1” if you wish to configure the network on LAN 1 (PoE).
Select “LAN2” to set up the network on LAN 2.
Enter the VLAN ID you want to use (0 - 4094)
Select HEX or ASCII.
Select 64-bit, 128-bit, or 152-bit.
Select the 1st key all the way through the 4th key, to be set as the
active key. Enter key here.
Security:
Ethernet:
VLAN ID:
Key Type:
Key Size:
Key:
When Primary SSID is set to any of
the following security levels:
Multi-SSID can use any of these
security levels:
None
Open System (WEP)
Shared Key (WEP)
WPA-Personal
WPA2-Personal
WPA-Auto-Personal
None
Open System (WEP)
Shared Key (WEP)
WPA-Personal
WPA2-Personal
WPA-Auto-Personal
WPA-Enterprise
WPA2-Enterprise
WPA-Auto-Enterprise
None
Open System (WEP)
Shared Key (WEP)
WPA-Personal
WPA2-Personal
WPA-Auto-Personal
WPA-Enterprise
WPA2-Enterprise
WPA-Auto-Enterprise
Cipher Type:
Group Key Update
Interval:
Select the interval during which the group key will be valid. The
default value of 1800 is recommended.
When you select WPA-Personal, please select AUTO, AES, or TKIP
from the pull down menu.
PassPhrase:
When you select WPA-Personal, please enter a PassPhrase in
the corresponding field.
