43
D-Link DWL-8200AP User Manual
SubMask:
Gateway:
Wins:
DNS:
Domain Name:
Status:
Enter the subnet mask here.
Enter the IP address of the gateway on the network.
Windows Internet Naming Service is a system that determines
the IP address of a network computer with a dynamically assigned
IP address, if applicable.
Enter the IP address of the Domain Name Server, if applicable.
The DNS translates domain names such as www.dlink.com into IP
addresses.
Enter the domain name of the DWL-8200AP, if applicable.
This option turns the Static Pool settings ON or OFF.
