High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 79
Multi-section
frequency
terminal 1
Multi-section
frequency
terminal 3
Multi-section
frequency
terminal 2
Multi-section
frequency
terminal 1
Setting frequency
OFF OFF OFF OFF
Open loop frequency
P0.05
OFF OFF OFF ON
Multi-section
frequency 1
OFF OFF ON OFF
Multi-section
frequency 2
OFF OFF ON ON
Multi-section
frequency 3
OFF ON OFF OFF
Multi-section
frequency 4
OFF ON OFF ON
Multi-section
frequency 5
OFF ON ON OFF
Multi-section
frequency 6
OFF ON ON ON
Multi-section
frequency 7
ON OFF OFF OFF
Multi-section
frequency 8
ON OFF OFF ON
Multi-section
frequency 9
ON OFF ON OFF
Multi-section
frequency 10
ON OFF ON ON
Multi-section
frequency 11
ON ON OFF OFF
Multi-section
frequency 12
ON ON OFF ON
Multi-section
frequency 13
ON ON ON OFF
Multi-section
frequency 14
ON ON ON ON
Multi-section
frequency 15
6.6 Multi-functional Input Parameter (Group P5)
P5.00 X1 terminal input function selection
0~99(99)
P5.01 X2 terminal input function selection 0~99(99)
P5.02 X3 terminal input function selection
0~99(99)
P5.03 X4 terminal input function selection
0~99(99)
P5.04 X5 terminal input function selection
0~99(99)
P5.05 X6 terminal input function selection
0~99(99)
0~99(99)
X7 terminal input function selection
P5.06
