High Performance Vector Control/Torque Control Inverter User Manual
Chapter 5 List of Parameters 57
Pd.25 Zero servo enable 0 0~1 / ○
0: Zero servo invalid;
1: zero servo valid;
Pd.26
Zero servo initial frequency
0.30
0.0~10.0 Hz ○ 0.0~10.0Hz
Pd.27
Zero servo gain
1.000
1.000~9.999
/ ○ 1.000~9.999
Pd.28
Static friction compensat
ion
coefficient
0.0
0.0~200.0 % ○ 0.0~200.0%
Pd.29
Sliding friction
compensation coefficient
0.0
0.0~200.0 % ○ 0.0~200.0%
Pd.30
Rotation inertia
compensation coefficient
0.0
0.0~200.0 % ○ 0.0~200.0%
Pd.31
Rotation inertia
compensation frequency
upper limit 1
0.0
0.0~300.0 Hz ○ 0.0~300.0Hz
Pd.32
Rotation inertia
compensation frequency
upper limit 2
50.00
0.0~300.0 Hz ○ 0.0~300.0Hz
Pd.33
Torque limiting
compensation coefficient in
constant power zone
40.0
0.0~100.0 % ○ 0.0~100.0%
Pd.34 Reserved 28
0~65535 / ○ 0~65535
Pd.35 Reserved 1500
0~65535 / ○ 0~65535
Pd.36 Torque taper 0 0~65535 / ○ 0~65535
PE.00 Reserved - 0～FFFF / ○ 0～FFFF
Group d0 Fault Record Parameters
d0.00 Fault type record 2 0 0~62 / *
d0.01 Fault type record 1 0 0~62 / *
d0.02 Latest fault type record 0 0 0~62 / *
Refer to 7.1 fault and alarm
information list
d0.03 Bus voltage of latest fault 0 0~999 V * 0~999V
d0.04 Actual current of latest fault
0.0
0.0~999.9 A * 0.0~999.9V
d0.05
Operation frequency of the
latest fault
0.00
0.00~300.00
Hz * 0.00~300.00Hz
d0.06 Total power-up time on time
0.000
0.000~65.535
kh * 0.000~65.535kh
d0.07
Total operation time of the
inverter
0.000
0.000~65.535
kh * 0.000~65.535kh
d0.08
Record of maximum
temperature of heatsink
0.0
0.0~100.0 ºC * 0.0~100.0ºC
d0.09
Record of maximum bus
voltage fluctuation
0 0~1000 V * 0~1000V
d0.10 Reserved 0.00
0.00~300.00
Hz * 0.00~300.00Hz
d0.11 Reserved 0 0~5 / * 0~5
Group d1 Product Identity Parameters
d1.00 Serial number Factory 0.0~FFF.F
/ * 0 ~ FFF.F
d1.01
Software version number
of
control board
Factory 0.00~99.99
/ * 0.0~99.99
d1.02
Non-standard version
number of software of
control board
Factory 0.00~FF.FF
/ * 0.00~FF.FF
d1.03
Software version number
of
operation panel
Factory 0.000~F.FFF
/ * 0.000~F.FFF
d1.04
Software v
ersion number of
extension board
Factory / * 0.000~F.FFF
d1.05 Manufacture’s bar code 1
Factory 0 ~ 9999 / * 0 ~ 9999
d1.06 Manufacture’s bar code 2
Factory 0 ~ 9999 / * 0 ~ 9999
d1.07 Manufacture’s bar code 3
Factory 0 ~ 9999 / * 0 ~ 9999
d1.08 Manufacture’s bar code 4
Factory 0 ~ 9999 / * 0 ~ 9999
d1.09 Operation panel copy Factory 0.00 ~ 655.35
/ * 0.00 ~ 655.35
