High Performance Vector Control/Torque Control Inverter User Manual
56 Chapter 5 List of Parameters
master to slave (set by
master)
function code of slave
0: P0.05; 1: P8.00; 2: P8.01;
PC.06
Slave setting frequency
proportional coefficient(set
by slave)
1.00
0.00 ~ 10.00
/ ○ 0.00 ~ 10.00
Group Pd Vector Control 2 Parameters
Pd.00 Speed/torque control 0 0 ~ 1 / ○
0: Speed control;
1: Torque control
2.00
Vector control 2
without encoder
speed feedback
Pd.01
Speed loop proportional
gain 1
(ASR_P1)
3.00
0.000 ~ 30.00
/ ○
Vector
control 2 with
encoder speed
feedback
0.000~30.00
Pd.02
Speed loop integral time 1
(ASR_I1)
0.200
0.000 ~ 6.000
s ○ 0.000 ~ 6.000s
2.000
Vector control 2
without encoder
speed feedback r
Pd.03
Speed loop proportional
gain 2 (ASR_P2)
3.00
0.000 ~30.00
/ ○
Vector
control 2 with
encoder speed
feedback
0.000~30.00
Pd.04
Speed loop integral time 2
(ASR_I2)
0.200
0.000 ~ 6.000
s ○ 0.000 ~ 6.000s
Pd.05 ASR switching frequency 5.00
0.00 ~ 300.00
Hz ○ 0.00 ~ upper frequency limit P0.13
Pd.06
Maximum speed limit for
forward running when
torque control
50.00
0.00 ~ 300.00
Hz ○ 0.00 ~ upper frequency limit P0.13
Pd.07
Maximum speed limit for
reverse running when
torque control
50.00
0.00 ~ 300.00
Hz ○ 0.00 ~ upper frequency limit P0.13
Pd.08 Drive torque limit 180.0
0.0 ~ 200.0
% ○
Constant torque: 0.0 ~ 200.0%
Variable torque: 0.0 ~ 150.0%
Pd.09 Braking torque limit 180.0
0.0 ~ 200.0
% ○
Constant torque: 0.0 ~ 200.0%
Variable torque: 0.0 ~ 150.0%
Pd.10 Reserved 4 0 ~ 65535 / ○ Reserved
Pd.11 Reserved 0.010
0.000 ~ 65.535
s ○ Reserved
Pd.12 Torque acceleration time 0.10
0.00 ~ 120.00
s ○ 0.00 ~ 120.00s
Pd.13 Torque deceleration time 0.10
0.00 ~ 120.00
s ○ 0.00~120.00s
Pd.14 Pre-magnetizing time 0.300
0.000 ~ 8.000
s ○ 0.000 ~ 8.000s
Pd.15
Current loop scale
coefficient (ACR_P)
1000
0 ~ 2000 / ○ 0 ~ 2000
Pd.16
Current loop integral
coefficient (ACR_I)
1000
0 ~ 6000 / ○ 0 ~ 6000
Pd.17
Vector control 2 slip
compensation gain
(electric)
100.0
10.0 ~ 300.0
% ○ 10.0 ~ 300.0%
Pd.18
Vector control 2 slip
compensation gain (power
generation)
100.0
10.0~300.0
% ○ 10.0 ~ 300.0%
Pd.19 ASR input filtering time 0.5
0.0~500.0 ms
○ 0.0~500.0
Pd.20 ASR output filtering time 0.5
0.0~500.0 ms
○ 0.0~500.0
Pd.21
Number of pulses per turn
for encoder
(vector control 2 with
encoder speed feedback)
1024
1~9999 / * 1 to 9999 pulses/turn
Pd.22 Encoder direction selection
0 0~1 / * 0: Forward; 1: Reverse
Pd.23
Interrupt detection time of
encoder
2.0
0.0~8.0 S * 0.0~8.0
Pd.24
Deceleration ratio between
motor and encoder
1.000
0.001~65.535
/ ○ 0.001~65.535
