High Performance Vector Control/Torque Control Inverter User Manual
118
Chapter 6 Parameter Description
is low. Current oscillation will be occurred as a result of setting I gain to extremely high.
When loads increase, motor slip will increase, but the rotating speed will decrease. The speed of motor
can be controlled constantly by slip compensation. Please make adjustments according to below
conditions:
When the motor speed is below the setting target value, increase vector control slip compensation gain.
When the motor speed is above the setting target value, decrease vector control slip compensation gain.
Note: When the temperature of motor increases, interior parameters of motor will change and the slip will
increase. Adjusting the function code can help to compensate the effects from temperature rise of motor.
When loads increase, motor’s slip will increase, and the rotating speed will also increase. The speed of
motor can be controlled constantly by slip compensation. Please make adjustments according to below
conditions:
When the motor speed is below the setting target value, decrease vector control slip compensation gain.
When the motor speed is above the setting target value, increase vector control slip compensation gain.
Note: When the temperature of motor increases, interior parameters of motor will change and the slip will
increase. Adjusting the function code can help to compensate the effects from temperature rise of motor.
This function defines the input filtering time of speed adjuster (ASR). In general, it needs no
modification.
This function defines the input filtering time of speed adjuster (ASR). In general, it needs no
modification.
It is used upon vector control 2 with encoder speed feedback. The number of pulses per turn for
encoder must be defined. This parameter shall be set properly according to the number of pulses per
turn of the encoder.
0: Forward
1: Reverse
The leave-factory value is 0. If the wiring sequence for connecting the encoder to inverter connection
board does not match the wiring sequence for connecting inverter to motor, this parameter may be set to
“1” to adjust the wiring sequence to avoid re-wiring.
Pd.23 is used to define the interrupt detection time for encoder signal upon vector control 2 with
encoder speed feedback. If the encoder interrupt time exceeds the time set in Pd.23, the inverter will
report E.dL1 error.
Pd.17 Vector control slip compensation gain (electric) 10.0~300.0 %( 100.0%)
Pd.18 Vector control slip compensation gain (power generation)
10.0～300.0 %（100.0%）
Pd.19 ASR input filtering time
0.0～500.0 ms（0.5ms）
Pd.20 ASR output filtering time 0.0～500.0 ms（0.5ms）
Pd.22 Encoder direction selection (V8 without this function)
0～1（0）
Pd.23 Interrupt detection time of encoder (V8 without this function)
0.0~8.0 s（2.0s）
Number of pulses per turn for encoder (vector control 2
with encoder speed feedback)
(V8 without this function)
1~9999 pulses/turn（1024）
Pd.21
