High Performance Vector Control/Torque Control Inverter User Manual
120
Chapter 6 Parameter Description
When the system is under torque control mode, if the system load inertia is large, additional rotation
inertia compensation shall be provided during the acceleration/deceleration of the system. The
compensation determined by the rotation inertia compensation coefficient Pd.30 is valid only when it is
less than Pd.31 which corresponds to the rotation inertia compensation frequency upper limit 1.
Note: It shall be ensured that the normal and stable running frequency of the inverter is above the
rotation inertia compensation frequency upper limit 1. Pd.32, the rotation inertia compensation frequency
upper limit 2, is generally set as the maximum frequency of the inverter.
This parameter compensates the torque limiting of the constant power zone. The
acceleration/deceleration time and output torque of the inverter when running in constant power zone
can be optimized by changing this parameter.
When the system is in torque control mode, the inertial the final output torque of the inverter can be
optimized by adjusting parameter Pd.36.
6.15 Failure Record Parameters (Group d0)
The inverter can record the latest three fault' code serial number (see 7.1 list of failure and alarm
information) and bus voltage, output current and operation frequency during failures recently occurred for
the ease of Trouble Shooting and repair.
Note: Upon the under-voltage display (LU), the parameters of fault type and failure time will not be saved.
d0.00 Fault type record 2
0~62(0)
d0.01 0~62(0)
d0.02 (Latest) Fault type record 0
0~62(0)
d0.03 Bus voltage of the latest failure
0~999 V(0V)
d0.04 Actual current of the latest failure 0.0~999.9 A(0.0A)
d0.05 Operation frequency of the latest failure
0.00~300.00 Hz (0.00Hz)
Fault type record 1
Pd.30 Rotation inertia compensation coefficient(V8 without this
function)
0.0～100.0 %（0.0%）
Pd.31 Rotation inertia compensation frequency upper limit 1(V8
without this function)
0.00～300.00 Hz（0.00Hz）
Pd.32 Rotation inertia compensation frequency upper limit 2(V8
without this function)
0.00～300.00 Hz （50.00Hz）
Pd.33
Torque limiting compensation coefficient of constant
power zone
0.0～100.0 %（40.0%）
Pd.34 Reserved
0～65535（28）
Pd.35
0～65535（1500）
Pd.36 Torque taper (V8 without this function)
0～65535（0）
Reserved
