High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 121
The inverter can record automatically the following information: Total power-up time of inverter, total
operation time of inverter, record of maximum temperature of heat-sink, record of maximum bus voltage
fluctuation.
6.16 Product Identity Parameters (Group d1)
Software version number and non-standard version number of product represent the software type. Each
inverter has a unique bar code for identification of product and determining product information.
d0.06 Total power-up time of inverter
0.000~65.535 kh(0.000kh)
d0.07 Total operation time of inverter
0.000~65.535 kh(0.000kh)
d0.08
Record of maximum temperature of heatsink
0.0~100.0 ºC(0.0ºC)
d0.09 Record of maximum bus voltage fluctuation
0~1000V(0V)
d0.10 Reserved
0.00~300.00Hz(0.00Hz)
d0.11 Reserved
0~5(0)
d1.00 Serial number
0.0~FFF F
d1.01 Software version number of control panel 0.00~99.99
d1.02 Non-standard version number of software of control panel
0.00~FF.FF
d1.03 Software version number of operating panel 0.000~F.FFF
d1.04 Software version number of extended panel 0.000~F.FFF
d1.05 Manufacturer’s bar code 1
0~9999
d1.06 Manufacturer’s bar code 2
0~9999
d1.07 Manufacturer’s bar code 3 0~9999
d1.08 Manufacturer’s bar code 4
0~9999
d1.09 Operation panel copy identification code
0.00~655.35
d1.10 Control board software identification cod
0~65535
d1.11 Reserved
0~65535
