High Performance Vector Control/Torque Control Inverter User Manual
66 Chapter 6 Parameter Description
Fig.6-2 Characteristic parameter definition
Effect of the torque boost function: Upon the vector control 1, when the inverteroperation at
low-frequency, increase the output voltage, and offset the stator voltage drop to product enough torque,
so as to ensure the normal operation of the motor.
Note:
The torque increase amplitude shall be set according to the load situation. Excessive increase
will cause large current impact during the startup process.
When P0.16 is set as 0.0, and P4.00 is set as 0 (linear V/F curve), the automatic torque increase
mode is adopted; when P4.00 is set as a non-zero value, the automatic torque increase mode is
disabled.
P0.16 Torque boost 0.0~30.0 %(0.0%)
