High Performance Vector Control/Torque Control Inverter User Manual
Chapter 3 Wiring of Incerter 27
Note: The short circuit plate between terminal +24V and terminal PLC must be removed.
The wiring modes of the multi-functional output terminals when the internal +24V power supply of the
inverter and external power supply are used
Note: When this wiring mode is adopted, if Y1 or Y2 terminal is damaged, the polarity of the external
diode must be checked to ensure the correctness.
User
controller
Inside of
inverter
The near end of the
+24
+24V
Inside of inverter
The near end of
the shielding cable
is grounded
User
Controller
Inside of inverter
Relay
+24
Inside of inverter
Relay
+24V
Inside of inverter
Relay
+24
Inside of inverter
Relay
+24V
