High Performance Vector Control/Torque Control Inverter User Manual
Chapter 3 Wiring of Incerter 25
Type
Terminal
symbol
Terminal function
description
Technical specification
Relay output
RA/RB/RC
Relay output
RA-RB: Normally closed
RA-RC: Normally open
Contact capacity: 250VAC/1A, 30VDC/1A
Note: ﹡ If the user connects adjustable potentiometer between ＋10V and GND, the resistance of the
potentiometer shall be no less than 5kΩ,
Note:
1. The arrangement sequence of the control circuit terminals is as follows:
+10V AI1
AI2
AI3 GND
AO1
AO2 GND
485+
485- RA
RB
RC
+24V
PLC COM X1 X2 X3
X4
X5 X8 X7/DI
Y1
Y2/DO
COM
+10V AI1
AI2
AI3 GND
AO1
AO2 GND
485+
485- RA
RB
RC
+24V
PLC COM X1 X2 X3
X4
X5 X8 X7/DI
Y1
Y2/DO
COM
2. Wiring mode of the multi-functional input/output terminals
When the internal +24V power supply of the inverter is used, the external controller adopts NPN sink
current wiring mode.
When the internal +24V power supply of the inverter is used, the external controller adopts PNP
draw-off current wiring mode.
User
controller
Inside of inverter
The near end of the
shielding
cable is grounded
+24
User
Controller
Inside of inverter
The near end of
the shielding cable
is grounded
+24V
