High Performance Vector Control/Torque Control Inverter User Manual
Chapter 5 List of Parameters 51
P7.24
Virtual terminal effective
selection
000
0 ~ 111 / ○
LED ones place: Multi function
input terminal Xi
0: Real terminal is enabled;
1: Virtual terminal is enabled
LED tens place: Reserved
LED hundreds place:
Y1/Y2/Relay terminal
0: Real terminal is enabled;
1: Virtual terminal is enabled
P7.25
Terminal effiective status
selection
000
0 ~ 1111 / ○
Ones place: Multi function input
terminal Xi
0: Current through Xi is valid;
1: No current through Xi is valid
Tens place: Multi function output
terminal Yi
0: Current through Yi is valid;
1: No current through Yi is valid
Hundreds place: relay terminal
0: Enabled in magnetizing status;
1: Enabled if not in magnetizing
status
Group P8 Process PID Close Loop Control
P8.00
Analog feedback process
close loop control digital
voltage reference
0.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P8.01
Single phase pulse
feedback process close
loop control digital RPM
reference
0 0 ~ 30000 rpm
○ 0 ~ 30000rpm
P8.02
Number of pulse per turn
for single phase pulse
1000
1 ~ 9999 / × 1 ~ 9999
P8.03 Proportional gain KP 0.200
0.000 ~ 10.000
/ ○ 0.000 ~ 10.000
P8.04 Integral gain Ki 0.500
0.000 ~ 10.000
/ ○ 0.000 ~ 10.000
P8.05 Differential gain Kd 0.000
0.000 ~ 10.000
/ ○ 0.000 ~ 10.000
P8.06 Sampling cycle 0.002
0.001 ~ 30.000
s ○ 0.001 ~ 30.000s
P8.07 Deviation limit 5.0
0.0 ~ 20.0 % ○ 0.0 ~ 20.0%
P8.08 PID adjustment selection 10
0 ~ 11 / ○
Ones place: Integral mode
0: Frequency reaches
upper/lower limit, stop integral
regulation;
1: Frequency reaches
upper/lower limit, continue
integral regulation
Tens place: output frequency
0: Be consistent with preset
direction;
1: Reverse to preset direction
P8.09
PID positive or negative
functio
0 0 ~ 1 / ○ 0 ~ 1
P8.10
Reserved function code 2 of
P8 group
0 0 ~ 65535 / ○ 0 ~ 65535
Group P9 Motor Parameter
P9.00 Load type 0 0 ~ 1 / ×
0: G type constant torque/
heavy duty application;
1: L type variable torque/ light
duty application
P9.01 Number of motor poles 4 2 ~ 24 / × 2 ~ 24
