High Performance Vector Control/Torque Control Inverter User Manual
Chapter 5 List of Parameters 47
Function
code
number
Function code name
Factor
y
setting
Setting range
Unit
Property
Function code selection
User
setting
P3.05 Stop mode 0 0 ~ 2 / ×
0: Deceleration to stop;
1: Coast to stop;
2: Deceleration to stop+DC braking
P3.06 DC braking initial frequency
0.00
0.00 ~ 300.00
Hz × 0.00 ~ 300.00Hz
P3.07 DC braking current 0.0
0.0 ~ 120.0
% ×
Constant torque: 0.0 ~ 120.0%
inverter rated current
Variable torque: 0.0 ~ 90.0%
inverter rated current
P3.08 DC braking time 0.00
0.0 0~ 30.00
s × 0.00~ 30.00s
P3.09 Anti-reverse selection 1 0 ~ 1 / ×
0: Run reverse enabled;
1: Run reverse disabled
P3.10
Forward / reverse dead
zone time
0.0
0.0 ~ 3600.0
s × 0.0 ~ 3600.0s
P3.11 Jog frequency 5.00
0.10 ~ 300.00
Hz × 0.10 ~ 300.00Hz
P3.12 Jog acceleration time 6.0
0.1 ~ 60.0 s × 0.1 ~ 60.0s
P3.13 Jog deceleration time 6.0
0.1 ~ 60.0 s × 0.1 ~ 60.0s
Group P4 Multi-section Parameter
P4.00 V/F curve reference 0 0 ~ 6 / ×
0: Direct line;
1: Multi-section (P4.01 ~ P4.08);
2: Power of 1.2;
3: Power of 1.4;
4: Power of 1.6;
5: Power of 1.8;
6: Power of 2
P4.01 V/F frequency value F0
0.00
0.00 ~ 300.00
Hz × F0<F1
P4.02 V/F voltage value V0
0.0
0.0 ~ 100.0
% × 0.0 ~ 100.0%
P4.03 V/F frequency value F1
0.00
0.00 ~ 300.00
Hz × F1<F2
P4.04 V/F voltage value V1
0.0
0.0 ~ 100.0
% × 0.0 ~ 100.0%
P4.05 V/F frequency value F2
0.00
0.00 ~ 300.00
Hz × F2<F3
P4.06 V/F voltage value V2
0.0
0.0 ~ 100.0
% × 0.0 ~ 100.0%
P4.07 V/F frequency value F3
0.00
0.00 ~ 300.00
Hz × F3< Motor basic frequency P0.15
P4.08
V/F voltage value V3
0.0
0.0 ~ 100.0
% × 0.0 ~ 100.0%
P4.09
Acceleration time 1
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.10
Deceleration time 1
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.11
Acceleration time 2
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.12
Deceleration time 2
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.13
Acceleration time 3
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.14
Deceleration time 3
20.0
0.1 ~ 3600.0
s × 0.1 ~ 3600.0s
P4.15
Multi-section digital voltage
reference 1
1.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.16
Multi-section digital voltage
reference 2
2.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.17
Multi-section digital voltage
reference 3
3.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.18
Multi-section digital voltage
reference 4
5.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.19
Multi-section digital voltage
reference 5
6.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.20
Multi-section digital voltage
reference 6
8.00
0.00 ~ 10.00
V ○ 0.00 ~ 10.00V
P4.21
Multi-section digital voltage
reference 7
10.00
0.00 ~ 10.
00
V ○ 0.00 ~ 10.00V
P4.22 Multi-section frequency 1
5.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.23 Multi-section frequency 2
8.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
