High Performance Vector Control/Torque Control Inverter User Manual
Chapter 5 List of Parameters 45
Function
code
number
Function code name
Factor
y
setting
Setting range
Unit
Property
Function code selection
User
setting
auxiliary calculation
2: Auxiliary-50%;
3: Main + Auxiliary-50%;
4: Take maximum value;
5: Take minimum value
P1.05
A
nalog feedback close loop
control main feedback
mode
1 1 ~ 4 / ×
1: AI1; 2: AI2;
3: AI3; 4: DI
P1.06
A
nalog feedback close loop
control auxiliary feedback
mode
0 0 ~ 4 / ×
0: None;
1: AI1; 2: AI2;
3: AI3; 4: DI
P1.07
Analog feedback
close loop
control feedback main and
auxiliary calculation
0 0 ~ 5 / ×
0: Main + Auxiliary;
1: Main - Auxiliary;
2: Auxiliary-50%;
3: Main + Auxiliary-50%;
4: Take maximum value;
5: Take minimum value
P1.08
Process open loop and
close loop composite
operation relationship
calculation
0 0 ~ 1 / ×
0: Open loop frequency
reference+ frequency after
closed loop PDI adjustment;
1: O
pen loop frequency reference
－ frequency after closed loop
PDI adjustment
Group P2 Key and Display Parameters
P2.00 Key-lock function selection
0 0 ~ 3 / ○
0: No locking;
1: Locking all keys;
2: Locking all keys except MULTI
key;
3: Locking all keys except RUN
and STOP/RST keys
P2.01 Multi-function key definition
1 0 ~ 8 / ○
0: No function;
1: Jog function;
2: Emergent shutdown 1(Stop in
shortest time);
3: Emergent shutdown 2
(Coast-to-stop);
4: Switch of input method of
running command
(Operation panel/Terminal/Host
computer);
5: Function code display switch
(fast/all);
6: Function code display
switching (different from
leave-factory/all);
7: Function code display
switching (the last changed 10
function codes/all);
8: Function code display
switching (P0.02 menu mode
switching)
