High Performance Vector Control/Torque Control Inverter User Manual
Appendix A Modbus Communication Protocol
139
The bits for the control command word (0x8000) of the inverter are defined as follows:
Bit Meaning Bit Meaning
0
0: Stop
command enable
1: Running
command enable
3
0: Jog command
disable
1: Jog command
enable
1
0: Forward
rotation
1: Reverse
rotation
14
0: Emergency stop
disable
1: Emergency stop
enable
2
0: Reset
command disable
1: Reset
command enable
15
0: Coast to stop
disable
1: Coast to stop
enable
Note: Bits 4 ~ 13 are reserved.
The bits for the status word1 (0x810B) of the inverter are defined as follows:
Bit
Meaning Bit Meaning
0 0: Inverter stop 1: Inverter running
3 0: Forward rotation 1: Reverse rotation
5~6
Running command reference mode selection:
0: Operation panel reference,
1: Terminal reference,
2: host computer reference.
4 0: Button unlocked 1: Button locked 8 ~ 15
0: Normal; others: Failure code
Note: Bits 1, 2 and 7 are reserved.
The bits for the status word 4(0x810E) of the inverter are defined as follows:
Bi
t
Meaning Bit
Meaning
0 0: Non-jog running 1: Jog running 5
0: Non-open loop
multi-section voltage
operation
1: Open loop
multi-section voltage
operation
1
0: Non-close loop
operation
1: Close loop
operation
6 0: Normal voltage 1: Under voltage
2
0: Non-open loop multi-section frequency
operation
1: open loop multi-section frequency operation
7
0: Non-single phase
pulse input close loop
operation
1: Single phase pulse
input close loop
operation
3
0: Non-close loop multi-section frequency
operation
1: Close loop multi-section frequency
operation
14
0: Speed control 1: Reserved
4
0: Non-common
operation
1: Common
operation
15
0: vector control 1 1: Vector control 2
Note: Bits 8 ~ 13 are reserved.
Special register for input password authentication
Attached Table-4
Sub function
code of PDU
Meaning
0xF000
Inverter user password P0.00 authentication, and it will be closed automatically if no operation
is performed within five minutes.
0xF001
PE.00 password authentication for the display and hidden areas of the specially authenticated
function codes of the inverter, and it will be closed automatically if no operation is performed
within five minutes.
0xF002
A0.00 password authentication for the display and hidden attributes customized areas of the
function codes of the inverter, and it will be closed automatically if no operation is performed
within five minutes.
