High Performance Vector Control/Torque Control Inverter User Manual
46 Chapter 5 List of Parameters
Function
code
number
Function code name
Factor
y
setting
Setting range
Unit
Property
Function code selection
User
setting
P2.02
Display parameter
selection
at running
1CB0
0 ~ FFFF / ○
LED ones place:
0: Reference frequency (Hz);
1: Bus voltage (V);
2: AI1(V); 3: AI2(V);
4: AI3(V); 5: DI (%);
6: External counting;
7: Motor rotation speed (rpm);
8: Close loop reference (%);
9: Close loop feedback (%);
A: Reference torque (%);
B: Running frequency (Hz);
C: Output current (A);
D: Output torque (%);
E: Output power (kW);
F: Output voltage (V);
LED tens, hundreds, thousands
place: Same with above
P2.03
Display parameter
selection
at stopping
3210
0 ~ FFFF / ○
LED ones place:
0: Reference frequency (Hz);
1: Bus voltage (V);
2: AI1(V); 3: AI2(V);
4: AI3(V); 5: DI (%);
6: External counting;
7: Motor rotation speed (rpm);
8: Close loop reference (%);
9: Close loop feedback (%);
A: Reference torque (%);
B: Reserved;
C: Reserved;
D: Reserved;
E: Reserved;
F: Reserved;
LED tens, hundreds, thousands
place: Same with above
P2.04
Running proportion display
benckmark
0 0 ~ F / ○ 0 ~ F
P2.05
Running proportion display
coefficient
0.0
0.0 ~ 1000.0
% ○ 0 ~ 1000.0%
P2.06
Stopping proportion display
benckmark
0 0 ~ F / ○ 0 ~ F
P2.07
Stopping proportion display
coefficient
0.0
0.0 ~ 1000.0
% ○ 0 ~ 1000.0%
Group P3 Start/stop Parameter
P3.00 Startup mode 0 0 ~ 2 / ×
0: Normal startup;
1: Start after DC injection;
2: Flying startup
P3.01 DC injection current 0.0
0.0 ~ 120.0
% ×
Constant torque: 0.0 ~ 120.0%
inverter rated current
Variable torque: 0.0 ~ 90.0%
inverter rated current
P3.02 DC injection time 0.00
0.00 ~ 30.00
s × 0.00 ~ 30.00s
0.00
Vector
control 2 with
encoder speed
feedback
P3.03 Startup frequency
0.50
0.00 ~ 60.00
Hz ×
Other control mode
0.00
~frequency
upper limit
the lower
of P0.13
and
60.00Hz
P3.04
Startup frequency retention
time
0.0
0.0 ~ 3600.0
s × 0.0 ~ 3600.0s
