High Performance Vector Control/Torque Control Inverter User Manual
48 Chapter 5 List of Parameters
Function
code
number
Function code name
Factor
y
setting
Setting range
Unit
Property
Function code selection
User
setting
P4.24 Multi-section frequency 3 10.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.25 Multi-section frequency 4 15.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.26 Multi-section frequency 5 18.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.27 Multi-section frequency 6 20.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.28 Multi-section frequency 7 25.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.29 Multi-section frequency 8 28.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.30 Multi-section frequency 9 30.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.31 Multi-section frequency 10
35.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.32 Multi-section frequency 11
38.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.33 Multi-section frequency 12
40.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.34 Multi-section frequency 13
45.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.35 Multi-section frequency 14
48.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
P4.36 Multi-section frequency 15
50.00
0.00 ~ 300.00
Hz ○
Upper / lower frequency limit
(P0.13 ~ P0.14)
Group P5 Multi-functional Input Parameter
P5.00
X1 terminal input function
selection
99
0 ~ 99 / ×
P5.01
X2 terminal input function
selection
99
0 ~ 99 / ×
P5.02
X3 terminal input function
selection
99
0 ~ 99 / ×
P5.03
X4 terminal input function
selection
99
0 ~ 99 / ×
P5.04
X5 terminal input function
selection
99
0 ~ 99 / ×
P5.05
X6 terminal input function
selection
99
0 ~ 99 / ×
P5.06
X7/DI terminal input
function selection
99
0 ~ 99 / ×
Refer to Definition of multi
function input terminals of P5
group in Chapter 6
P5.07
X1 to X7 terminal filtering
time
0.001
0.000 ~ 1.000
s × 0.000 ~ 1.000s
P5.10
Maximum input pulse
frequency
10.0
0.1 ~ 50.0 kHz
× 0.1 ~ 50.0kHz
P5.11 Startup/stop mode s
election
0 0 ~ 3 / ×
0: 2-wire type 1;1: 2-wire type 2;
2: 3-wire type 1;3: 3-wire type 2;
P5.12
Preset counting value
reference
0 0 ~ 9999 / × 0 ~ 9999
P5.13
Reached counting value
reference
0 0 ~ 9999 / × 0 ~ 9999
