High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 83
49: Command switching to terminal
50: Command switching to host computer
The above three functions are set to facilitate the switching of running command reference mode. W hen
the terminal is switching from disabled status to enabled status, The edge trigger is valid.
51: Main frequency source close loop and open loop switching input
It is the process open loop operation and process close loop operation switching terminal. When this
terminal is enabled, it means process close loop operation and when the terminal is disable, it means
process open loop operation.
52: Main frequency source switching to digital voltage reference
54: Main frequency source switching to AI1
55: Main frequency source switching to AI2
56: Main frequency source switching to AI3
57: Main frequency source switching to DI
The above five functions are set to facilitate the switching of main frequency source. When the terminal is
switching from disabled status to enabled status, The edge trigger is valid. When this terminal is enabled,
it will switch from the current main frequency source mode to the main frequency source mode
corresponding to this terminal function.
58: Auxiliary frequency source switching to disabled
59: Reserved
60: Auxiliary frequency source switching to AI1
61: Auxiliary frequency source switching to AI2
62: Auxiliary frequency source switching to AI3
63: Auxiliary frequency source switching to DI
The above five functions are set to facilitate the switching of auxiliary frequency source. When the
terminal is switching from disabled status to enabled status, the edge trigger is valid. When this terminal
is enabled, it will switch from the current auxiliary frequency source mode to the auxiliary frequency
source mode corresponding to this terminal function.
64: Speed control/torque control switching (V8 without this function.)
This function shall be used together with the speed/torque control Pd.00 function code. Under vector
control 2, it can be switched between speed control mode and torque control mode through terminal. If
Pd.00 is set as 0 and the terminal function is invalid, it is under speed control. If the terminal function is
valid, it switches to torque control. If Pd.00 is set as 1 and the terminal function is invalid, it is under
torque control. If the terminal function is valid, it switches to speed control.
Terminal
Pd.00
Terminal function invalid Terminal function valid
0 Speed control Torque control
1 Torque control Speed control
65 Speed limiting forced to be Pd.06 and Pd.07 (V8 without this function.)
