Printing with the Finisher
117
3
Punching Precautions
Follow these precautions when using the punch function.
Important
❒ To use this function, the optional tray Finisher SR3040 and punch unit must
be installed on the printer.
❖ Punch printing will be canceled under the following conditions:
• When a paper type that cannot be punched is selected.
• When a paper size that cannot be punched is selected.
• If positions other than those fixed for punching are specified.
• If there are inconsistencies between the orientation in duplex mode and the
punch position.
• If there are inconsistencies between the orientation in letterhead mode and
the punch position.
• When feeding paper from the bypass tray.
• When the punch receptacle has become full and Auto Continue is set
(Printing will continue without punching after the message appears).
• If there are inconsistencies between the staple position and the punch po-
sition, when using with staple function.
EU 4 holes K
←
A4, B5, Letter
L
←
A3, B4, 11”×17”
Northern EU 4 holes K
←
B5, Letter
L
←
A3, B4, A4, B5, 11”×17”, Le-
gal, 8
1
/
2
”×13”, 8
1
/
4
”×13,
8”×13”, Letter, 5
1
/
2
”×8
1
/
2
”,
7
1
/
4
”×10
1
/
2
”
Type Feed Direction Paper Size
