Ricoh Aficio SP 8100DN [205/340] Hostname
![Ricoh Aficio SP 8100DN [205/340] Hostname](/views2/1064372/page205/bgcd.png)
Remote Maintenance by telnet
193
5
hostname
Use the “hostname” command to change the printer name.
❖ View settings
msh> hostname
❖ IPv4 Configuration
msh> hostname “interface_name ” “printer_name”
• Enter the printer name using up to 63 alphanumeric characters.
• You cannot use a printer name starting with “RNP” or “rnp”.
• The Ethernet interface and IEEE 802.11b interface will have the same print-
er name.
• wlan can be specified only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
❖ Initializing the printer name for each interface
msh>hostname “interface_name” clear “name”
ifconfig
Use the “ifconfig” command to view and configure TCP/IP (IP address, subnet
mask, broadcast address, default gateway address) for the printer.
❖ View settings
msh> ifconfig
❖ IPv4 Configuration
msh> ifconfig “interface_name” “parameter” “address”
• If you did not enter an interface name, it is automatically set to the Ethernet
interface.
• wlan can be specified only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
The following explains how to configure an IPv4 address 192.168.15.16 on
Ethernet interface.
msh> ifconfig ether 192.168.15.16
Interface name Interface configured
ether Ethernet interface
wlan IEEE 802.11b interface
Interface name Interface configured
ether Ethernet Interface
wlan IEEE 802.11b Interface
