Making Printer Settings Using the Control Panel
140
4
❖ Auto Del.Stored
This appears on the menu only when the hard disk is installed.
Specify whether to automatically delete saved documents (Stored Print data).
Also specify the elapse time in days before deletion.
❖ Auto Delete
•On
•Off
Note
❒ Default: Off
❖ Days to Delete
• 1 to 180 days by 1 day.
Note
❒ Default: 3 days
❖ Memory Usage
You can select memory to be used from “Font Priority” or “Frame Priority”.
• Font Priority
•Frame Priority
Note
❒ Default : Frame Priority
❖ Unit of Measure
You can specify the unit of measurement in “mm” or “inch” for the custom
paper size.
•mm
•inch
Note
❒ Default value is destination dependant.
❖ Edge Smoothing
•On
•Off
Note
❒ Default: On
❖ Toner Saving
•Off
•On
Note
❒ Default: Off
