Monitoring and Configuring the Printer
228
5
Login Mode
Print job timeout
Protocol
SAP interval time
NDS Tree Name NDS tree name
Transfer Protocol
SMB SMB Settings
Switch
Mode
Direct print
Notification
Workgroup name
Computer name
Comment
Share name[1]
Protocol
SCSI print
Bidi
IEEE 802.11b IEEE 802.11b Settings
Host name
Communication Mode
SSID
Channel range
Channel
TX Rate
Security
WEP Authentication
WEP Encryption key number
WEP Encryption keys[X] X can be set setween 1 and 5.
WPA Encryption
WPA Authentication
Pre-Shared Key
User name
Domain name
EAP Type
Item Description
